The Eagle Boiler Control System

Introducing The Eagle—a non-proprietary, and fully customizable Burner Control System (BCS) engineered to put the user first. Designed for reliability, seamless commissioning, and peak performance, this innovative solution is built to deliver proven results with unmatched flexibility.

The Eagle BCS meets or exceeds existing burner control systems with only high-quality, industry standard components. Unlike many other integrators, Nationwide Control Solutions utilizes open-source programming for the HMI and PLC, meaning that configuration programs are not locked up with proprietary passwords and protocols. Built to provide an easier method of operation, all air/fuel ratio 10pt curves are entered through a single HMI screen that displays the data required for burner tuning. This includes steam pressure (or outlet temperature), drum level, and percent oxygen.

Learn more about our Eagle BCS Packages below:

Eagle Basic Control Panel

The Eagle Basic Control Panel is our standard burner management / combustion control system, a parallel positioning design tailored specifically for firetube boilers.

This package includes:

• Fireye BMS YB110 Series
• Allen-Bradley Micro 850 PLC with 7” Touchscreen HMI
• NEMA 4 Powder Coated Steel Enclosure
• Any Fireye Flame Scanner
• Gas Only Setup (single fuel) OR Dual Fuel
• Boiler MFG supplied water level control
• Option to add water level relays
• Fireye Modbus Actuators

Eagle One Control Panel

The Eagle One Panel is our standard burner management / combustion control system for both watertube and firetube boilers, featuring traditional 4-20mA actuators. It supports fully metered combustion control and advanced communication capabilities.

This Package includes:

• Allen-Bradley CompactLogix PLC with 10” Touchscreen HMI
  • PLC Cards Selected Based on Application
• NEMA 4 Steel Enclosure
• Any Flame Scanner
• Gas Only Setup (single fuel) OR Dual Fuel
• Auxiliary Water Level Relay

Eagle Master Control Panel

Our Plant Master Control Panel is Nationwide’s design for managing multiple boiler/burner packages in a lead/lag configuration, with options for controlling deaerators, surge tanks, and other necessary steam plant auxiliary equipment.
The Master Control Panel package includes:

• Allen-Bradley CompactLogix PLC with 10” Touchscreen HMI

  • PLC Cards Selected Based on Application
• NEMA 4 Powder Coated, Mild Steel Enclosure

In addition to what's listed above, every Eagle BCS package offers some level of customization—customer logos on the HMI, modification of panel layouts, etc., and upgrade options including a stainless steel enclosure, climate controls, larger screen, various PLC upgrades, remote monitoring capabilities, and more.

Contact Nationwide Control Solutions today to learn more about how our Burner Control Systems can enhance the overall operation of your new or existing facility.

360-335-1443 | controls@nationwideboiler.com
